| Part Name | Technical parameters and models | Place of origin or others |
| Single Screw Extruder | ||
| A. Main machine | ||
| Hardened gearbox (reduction gearbox) | National standard 146*1 type 146*1 type | Changzhou, Jiangsu |
| Barrel screw | φ50 alloy screw*1φ55 alloy screw*1 | Zhoushan, Zhejiang |
| Screw material | 38CrMoAl | |
| L/D ratio | 32:01:00 | |
| Screw speed (r/min) | 0-85 | |
| Minimum film width (mm) | 280 | |
| Maximum film width(mm) | 200-600 | |
| Minimum film thickness (mm) | One side 0.01 | |
| Maximum film thickness (mm) | Single Side 0.10 | |
| Barrel cooling fan | 240W*4 | Shanghai |
| Barrel heating ring | Stainless steel heating ring | |
| Extruder main motor | 15Kw*1* 15KW*1 Frequency conversion speed control | Shanghai |
| Main machine inverter | 15Kw*1 15WK*1 | Shanghai Parnell |
| Temperature controller | Shanghai Yatai | |
| Head flange | Embedded | |
| Tee heating ring | Ceramic heating ring | |
| Hopper feeding method | Manual | |
| Main machine cover | Integral type | |
| Paint colour | Beige colour for main body type, blue-green colour match for railing | |
| Square steel frame | 10# | |
| Capacity | 20-40kg/h | |
| B. Haulage section | ||
| Total height of auxiliary machine | 4800mm Two levels of internal travelling | |
| Traction pressure roller adjustment mode | Manual adjustment | |
| Traction frame structure | Bolt-on type | |
| Length of traction roller (mm) | Roller surface length 900mm | |
| Traction motor | 2.2Kw Frequency control | Shanghai |
| Traction frequency converter | 2.2Kw | Shanghai Parnell |
| Traction speed (m/min) | 0----80 | |
| Stabilising film bubble device | Retainer bar type steady bubble rack (adjusted separately) | |
| Herringbone clamping plate | Wooden grill split type (separately adjustable) | |
| Guide roller diameter (mm) | 60mm (Aluminium) | |
| Diameter of haul-off roller (mm) | 130mm (Silicone) | |
| C. Winding section | ||
| Winder structure | Friction backrest rewind Single rewind | |
| Winding method | Friction rewind | |
| Diameter of rewinding roller (mm) | 250mm ( Horizontal diamond pattern) | |
| Length of rewinding roller (mm) | 700mm | |
| Winding motor | Three-phase torque motor | Shui On |
| Winding shaft structure | Ordinary shaft | |
| Paint colour | Beige | |
| D. Mould head portion | ||
| Mould calibre (mm) | 50, ABA die head | Guangzhou |
| Mould structure | Internal spiral, centre feed Rotating | |
| Die head heating ring | Stainless steel heating ring | |
| Machine head, die head material | 45# steel heat treated, chrome plated and polished | |
| Extruder output | 60-80kg per hour | |
| E. Cooling section | ||
| Wind ring and wind sheet configuration | 700 type double wind ring, according to the mould configuration wind piece | |
| Cooling blower | 2.2Kw | Taizhou |
| Temperature control mode | Intelligent double digital display type, temperature control table | Shanghai Yatai |
| F. Equipment size（mm) | L*W*H 5200*2000*4200 | |
| G. Equipment weight | 1800Kg |
