Home / Product / Pouch Machine / 800 Type High-Speed Automatic Broken Glue Express Bag Making Configuration List
  • Application

  • Product Specifications

    Technical indicators and main parameters Model:  RFQ-800 High-speed full-automatic broken glue express bag making machine
    Bag making speed 30~250pcs/min
    Bag width 50~800mm
    Bag Length 50~750mm
    Bag Thickness 40mm
    VOLTAGE 220v
    Total power 6.5kw
    Overall Dimension 3600×1300×1800mm
    Whole machine Weight 1280KG
    Elevated Rupture flap, express bag knife 1, horizontal reinforcement knife 8mm 1
    Unwinding unit Unwinding diameter 600mm
    Pneumatic perforator Made in Shenzhen
    Conveyor belt  Imported KODAK brand
    Automatic photoelectric tracking Domestic Julong
    Electric control length setting system of the whole machine Dedicated multi-motor dual servo drive system
    Unwinding system Automatic deskewing, Automatic loading, automatic tension
    Glue spraying Automatic glue spraying machine Made in Quanzhou
    DC motor Wuhu Deli
    Relay Omron
    Pneumatic components Yadek, Shenzhen, etc.
    Common electrical brands Temperature Display Shanghai temperature meter, display the surface temperature of preheating roller
    Commonly used electrical components/switches Astronergy
    Inverter Changsha Beside
    Inverter motor Shanghai Speed River
    Bearing Mostly imported from Japan
    Free accessories list Temperature control line 1, high temperature cloth 1, spring 30, random accessories, a set of tool box, a grease gun, all the manuals of this machinery.
